Premium Indoor LED Walls for Corporate, Education & Retail
AIDIA Prime is a premium indoor LED wall solution designed for environments that demand exceptional image quality, dependable performance, and a modern visual experience. Built with advanced LED technology, AIDIA Prime delivers vibrant colours, deep contrast, and crystal-clear visuals, making it the ideal choice for corporate offices, educational institutions, retail showrooms, hospitality venues, and public spaces. Whether you're presenting business data, engaging customers with digital content, or creating an immersive brand experience, AIDIA Prime ensures every image and video is displayed with outstanding clarity. Engineered for continuous operation, AIDIA Prime features high refresh rates, wide viewing angles, and precise colour calibration to provide a seamless viewing experience from every position. The slim cabinet design allows for easy installation while maintaining a sleek, professional appearance that complements any interior environment. Its energy-efficient design helps reduce power consumption without compromising brightness or performance. AIDIA Prime supports flexible configurations in various screen sizes, resolutions, and aspect ratios, allowing businesses to create customised display solutions that fit their space and objectives. From reception areas and conference rooms to university auditoriums, retail outlets, and experience centres, AIDIA Prime adapts effortlessly to diverse applications. Designed for long-term reliability, the system offers stable operation, easy front maintenance, and minimal downtime, ensuring uninterrupted performance even in demanding commercial environments. Combined with professional installation, technical support, and comprehensive maintenance services from AIDIA, Prime provides a complete display solution that delivers lasting value. Choose AIDIA Prime to transform your indoor spaces with brilliant visuals, reliable technology, and premium display performance that elevates communication, enhances customer engagement, and creates memorable experiences across every industry.
- Conference Centre
- Control Centre
- Broadcast
- Meeting Room
- Exhibition Centre
- Home Cinema
Product Highlights
Advanced Mechanical Design
• Perfect, easy alignment of displays in all axes for a homogeneous, flat appearance of the video wall • Highly precisely manufactured die-cast aluminium housing • Internal connectors for power and signal for a wireless setup of the video wall
Latest COB LED Technology
By using the latest COB flip-chip LED technology, the VDS series from Leyard offers a coated surface which, on the one hand, makes the image appear more homogeneous compared to traditional SMD LED displays and, on the other hand, automatically provides a protective surface
90° Angle Splicing
Optionally, the VDS Series LED displays can also be installed in 90° corners. This allows you to achieve more eye-catching and creative installations beyond the usual rectangular formats. This creates a barely visible ridge in the corner, which creates a perfect image impression, e.g. in naked-eye 3D applications.
Resistant Surface with Excellent Mechanical Robustness
As the surface is glued, the screen can be touched without any risk of damaging the LEDs by human static electricity. In addition, the protective surface enables easy cleaning of the wall and protection against external influences. The more than ten times increased hardness compared to SMD LEDs allows the use of the displays even in demanding environments with high public traffic, such as airports, railway stations, museums or public entrance areas.
Ultra-High Refresh Rate & Colour Space
Even the fastest video content is displayed razor-sharp and streak-free by the VDS series. The ultra-high refresh rates of 3840Hz at 14bit or 7680Hz at 12bit colour depth allow brilliant images even with highly dynamic moving pictures.
Built-in One-Key Energy Saving
In stand-by mode, the power supply to the modules is completely cut off. By sending a command through the processor, the cabinets can be placed in a low-power standby mode, reducing power consumption to as little as 3W per m².
Specifications
| Item | AEC0.78 |
|---|---|
|
Pitch (mm)
|
0.78
|
|
Module Size (mm)
|
150x168.75
|
|
Cabinet Resolution
|
768×432
|
|
Cabinet Dimension (WxHxD mm)
|
600×337.5×43.5
|
|
Unit Area (㎡)
|
0.2025
|
|
Pixel Density (pixel/㎡)
|
1638400
|
|
Brightness (nits) (after calibration)
|
600 (1000 optional)
|
|
Viewing Angle (H/V) (°)
|
170; 170
|
|
Max/Average Power (W/㎡)
|
425 & 550; 200 & 280
|
|
Color Temperature (K)
|
3000~10000 adjustable
|
|
Refresh Rate(Hz)
|
3840
|
|
Operation/Storage Temp(℃)
|
-10 ~ 40; -20 ~ 60
|
|
Operation/Storage Humidity(RH)
|
10~90%; 10~95%
|
| Item | AEC0.93 |
|---|---|
|
Pitch (mm)
|
0.935
|
|
Module Size (mm)
|
150x168.75
|
|
Cabinet Resolution
|
640×360
|
|
Cabinet Dimension (WxHxD mm)
|
600×337.5×43.5
|
|
Unit Area (㎡)
|
0.2025
|
|
Pixel Density (pixel/㎡)
|
1137777
|
|
Brightness (nits) (after calibration)
|
600 (1000 optional)
|
|
Viewing Angle (H/V) (°)
|
170; 170
|
|
Max/Average Power (W/㎡)
|
375 & 530; 175 & 265
|
|
Color Temperature (K)
|
3000~10000 adjustable
|
|
Refresh Rate(Hz)
|
3840
|
|
Operation/Storage Temp(℃)
|
-10 ~ 40; -20 ~ 60
|
|
Operation/Storage Humidity(RH)
|
10~90%; 10~95%
|
| Item | AEC1.25 |
|---|---|
|
Pitch (mm)
|
1.25
|
|
Module Size (mm)
|
150x168.75
|
|
Cabinet Resolution
|
480×270
|
|
Cabinet Dimension (WxHxD mm)
|
600×337.5×43.5
|
|
Unit Area (㎡)
|
0.2025
|
|
Pixel Density (pixel/㎡)
|
640000
|
|
Brightness (nits) (after calibration)
|
600 (1000 optional)
|
|
Viewing Angle (H/V) (°)
|
170; 170
|
|
Max/Average Power (W/㎡)
|
325 & 510; 160 & 260
|
|
Color Temperature (K)
|
3000~10000 adjustable
|
|
Refresh Rate(Hz)
|
3840
|
|
Operation/Storage Temp(℃)
|
-10 ~ 40; -20 ~ 60
|
|
Operation/Storage Humidity(RH)
|
10~90%; 10~95%
|
| Item | AED1.56 |
|---|---|
|
Pitch (mm)
|
1.56
|
|
Module Size (mm)
|
150x168.75
|
|
Cabinet Resolution
|
384×216
|
|
Cabinet Dimension (WxHxD mm)
|
600×337.5×43.5
|
|
Unit Area (㎡)
|
0.2025
|
|
Pixel Density (pixel/㎡)
|
409600
|
|
Brightness (nits) (after calibration)
|
600 (1000 optional)
|
|
Viewing Angle (H/V) (°)
|
170; 170
|
|
Max/Average Power (W/㎡)
|
325 & 510; 160 & 260
|
|
Color Temperature (K)
|
3000~10000 adjustable
|
|
Refresh Rate(Hz)
|
3840
|
|
Operation/Storage Temp(℃)
|
-10 ~ 40; -20 ~ 60
|
|
Operation/Storage Humidity(RH)
|
10~90%; 10~95%
|
